INCH-POUND

MIL-DTL-22641F

9 November 2011

SUPERSEDING

MIL-DTL-22641E

10 July 2006

DETAIL SPECIFICATION

ADAPTERS, COAXIAL TO WAVEGUIDE,

GENERAL SPECIFICATION FOR

This specification is approved for use by all Departments

and Agencies of the Department of Defense.

1. SCOPE

1.1 Scope. This specification covers the general requirements for adapters that connect series N connectors to

waveguides, 5/8-inch coaxial lines to waveguides, and 7/8-inch coaxial lines to waveguides, series TNC connectors

to waveguides, and series SMA connectors to waveguides, for general application by the armed services (see 1.2,

1.2. Classification. For the purpose of this specification, adapters are classed as follows (see 3.1):

Class 1 - Coaxial, series N to waveguides.

Class 2 - 5/8-inch coaxial lines to waveguides.

Class 3 - 7/8-inch coaxial lines to waveguides.

Class 4 - Coaxial, series TNC to waveguides.

Class 5 - Coaxial, series SMA to waveguides.

1.3 Part or Identifying Number (PIN). The PIN consists of the letter "M", the basic number of the specification

sheet, and an assigned dash number as shown in the following example (see 3.1):

22641/16

- 001

Military designator

Specification

Dash

sheet number

number

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This

section does not include documents cited in other sections of this specification or recommended for additional

information or as examples. While every effort has been made to ensure the completeness of this list, document

users are cautioned that they must meet all specified requirements of documents cited in sections 3 and 4 of this

specification, whether or not they are listed.

2.2 Government documents.

2.2.1. Specifications, standards and handbooks. The following specifications, standards and handbooks form a

part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are

those cited in the solicitation or contract (see 6.2).

Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime, ATTN:

VAT, Post Office Box 3990, Columbus, OH 43218-3990 or emailed to TubesAmps@dla.mil. Since contact

information can change, you may want to verify the currency of this address information using the ASSIST Online

AMSC N/A

FSC 5985
