INCH-POUND
MIL-A-3933/23C
20 January 2009
SUPERSEDING
MIL-A-3933/23B
30 June 1981
DETAIL SPECIFICATION SHEET
ATTENUATORS, FIXED, TO-5 CONFIGURATION,
CLASS IV, LOW POWER
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
Inactive for new design
after 4 June 1999
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-DTL-3933.
Dimensions are
Dimensions are
Ltr
Ltr
in inches
in inches
A
.250
e1
.100
L
.50 min
e
.200
.0175 ± .0015
D
.360
b
DIA LEAD TYP
D1
.325
K
.031 ± .003
J
.0345 ± .003
F
.067 ± .058
FIGURE 1. Flange - Continued.
AMSC N/A
FSC 5985
