MIL-A-3933/24C
Inches
mm
Inches
mm
Inches
mm
.010
.25
.102
2.59
.340
8.64
.02
.5
.20
5.1
.46
11.7
.03
.8
.250
6.35
.500
12.70
.04
1.0
.28
7.1
1.03
26.2
.062
1.57
.30
7.6
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ± .005 (.13 mm).
FIGURE 1. Dimensions and configuration. Continued
ENGINEERING DATA:
Operating frequency range:
2 to 12.4 GHz.
Basic test frequency:
8 GHz.
Operating temperature range: -55 ° C to +125 ° C. Power input is derated linearly from +25 ° C to 0.2 watt
at +125 ° C.
Maximum weight: 0.45 oz.
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Nominal impedance: 50 ohms.
Attenuation: See table I for attenuation values and tolerances.
VSWR: (1.07 + .015f) : 1 ( where f is the frequency in GHz).
Power input:
Average: 2 watts at 25° C.
Peak: 100 watts (Duty cycle of 5 percent and a maximum pulse width of 10 microseconds).
Part number: M3933/24- (and dash number from table I).
TABLE I. Attenuation values.
Dash number
Attenuation values.
01 N
10
± 0.3
S
02 N
15
±
0.5
S
03 N
20
± 0.5
S
NOTES : Attenuators covered by this specification sheet are substitutable for the manufacturer's part numbers
specified in table II. This information in no way implies that manufacturer's part number is suitable as a substitute for
the military part number.
Manufacturer's part
Military part number
NSN
Manufacturer's code
number
M3933/24-
01
97942
583R575410
5985-01-083-3368
02
97942
583R575415
-----
03
97942
583R575420
------
2
