MIL-DTL-15370/4E
TABLE I. Physical characteristics - Continued.
Dimensions 1/ 2/ 3/
Dash
Equivalent
Flange
Number
waveguide
A
B
C
Min
Max
Min
Max
Min
Max
019
5.975
8.750
1.630
1.938
.400
.719
M85/3-006
M3922/54-003 8/
(151.77)
(222.25)
(41.40)
(49.23)
(10.16)
(18.26)
(RG-96/U)
(UG-599/U)
020
7.20
7.40
1.51
1.55
.782
.820
M85/1-078
M3922/53-003
(182.88)
(187.96)
(38.35)
(39.37)
(19.86)
(20.83)
(UG-135/U) 5/
021
7.20
7.40
1.51
1.55
.782
.820
M85/1-077
M3922/59-008
(182.88)
(187.96)
(38.35)
(39.37)
(19.86)
(20.83)
(RG-67/U)
(UG-136B/U) 6/
022
7.20
7.40
1.51
1.55
.782
.820
M85/1-077
7/
(182.88)
(187.96)
(38.35)
(39.37)
(19.86)
(20.83)
(RG-67/U)
023
13.50
13.95
1.875
1.879
.688
.706
M85/1-089
M3922/53-005
(342.90)
(354.33)
(47.63)
(47.73)
(17.48)
(17.93)
(RG-91/U)
(UG-419/U)
024
12.40
12.45
1.875
1.879
.688
.706
M85/1-089
M3922/53-005
(314.96)
(316.23)
(47.63)
(47.73)
(17.48)
(17.93)
(RG-91/U)
(UG-419/U)
025
12.40
12.45
1.875
1.879
.688
.706
M85/1-093
M3922/53-005
(314.96)
(316.23)
(47.63)
(47.73)
(17.48)
(17.93)
(RG-107/U)
(UG-419/U)
026
12.40
13.01
1.370
1.380
.688
.706
M85/1-089
M3922/53-005
(314.96)
(330.45)
(34.80)
(35.05)
(17.48)
(17.93)
(RG-91/U)
(UG-419/U)
027
12.40
15.00
1.630
1.938
.400
.719
M85/1-089
M3922/53-005
(314.96)
(381.00)
(41.40)
(49.23)
(10.16)
(18.26)
(RG-91/U)
(UG-419/U)
1/ Dimensions are in inches.
2/ Metric equivalents (to the nearest .01 mm) are given for general information only.
3/ Metric equivalents are in parentheses.
4/ Except the lip thickness is .25 inch (6.35 mm) and tapped holes .138-32UNC-2B.
5/ Except for tapped holes, .164-32UNC-2B in the input (1) flange.
6/ Except for clearance holes of .167/.179 dia in the output (2) flange.
7/ Input flange (1) is M3922/53-003 (8/), and the output and coupled flanges (2 and 3) are M3922/59-008. All
three flanges have threaded holes .164-32UNC-2B.
8/ MIL-DTL-3922/54 and MIL-DTL-3922/55 flange specification sheets are inactive for new design and no
longer used, except for replacement purposes.
4
