MIL-DTL-23971/3A
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance on decimals are ±.020 (.5 mm).
Dimensions
Inches
Millimeters
Max
Min
Max
Min
A
.580
.540
14.7
13.7
B
.385
.365
9.78
9.27
C
1.18
1.16
30.0
29.5
D
.260
.200
6.60
5.08
E
.185
.145
4.70
3.68
F
.140
.100
3.56
2.54
G
.132
.082
3.35
2.08
H
.125 dia
N/A
3.17 dia
N/A
J
.098 dia
.088 dia
2.49 dia
2.24 dia
K
.255
.195
6.48
4.95
L
1.448
1.428
36.78
36.27
M
.154
.114
3.91
2.90
N
.015
.005
.38
.13
P
.120
N/A
3.0
N/A
Q
1.640
1.600
41.7
40.6
R
.111
.071
2.82
1.80
S
.140
.100
3.56
2.54
FIGURE 1. Dimensions and configuration - Continued.
2
