MIL-DTL-287/4H
TABLE I. Flexible, nontwistable waveguide assemblies - Continued.
Group
1/ PIN
TE10 mode
Minimum centerline bending
Insertion
Pressur-
number
M287/4-
frequency
radius (inch)
loss
ization
2/ VSWR
(lbf/in2)
range (GHz)
(db/ft)
(max)
gage
at
E plane
H plane
>36"
12"
24"
36"
51-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
52-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
53-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
III
54-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
55-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
56-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
57-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
73-XXXX
12.4 - 18.0
1.25
2.00
0.25
60
1.13
1.15
1.19
1.24
58-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
59-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
60-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
III
61-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
62-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
63-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
74-XXXX
18.0 - 26.5
1.13
1.25
0.50
60
1.14
1.16
1.20
1.25
See footnotes at end of table I.
4
