MIL-DTL-3922/53E
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Material: Metallic alloy as specified in table I.
Marking: See figure 1.
PIN: M3922/53- (and dash number from table I).
TABLE II. Cross-reference and engineering information.
PIN
Frequency range
M3922/53-
AN nomenclature
(GHz)
001
UG-39/U
8.20 - 12.40
002
UG-51/U
7.05 - 10.00
003
UG-135/U
8.20 - 12.40
004
UG-138/U
7.05 - 10.00
005
UG-419/U
12.40 - 18.00
006
UG-1665/U
12.40 - 18.00
007
---
10.00 - 15.00
008
---
10.00 - 15.00
009
---
8.20 - 12.40
010
---
8.20 - 12.40
011
---
12.40 - 18.00
012
---
12.40 - 18.00
013
---
10.00 - 15.00
014
---
10.00 - 15.00
015
---
8.20 - 12.40
016
---
8.20 - 12.40
017
---
12.40 - 18.00
018
---
12.40 - 18.00
Referenced documents. In addition to MIL-DTL-3922, this specification sheet references the following documents:
ASME-B46.1
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the extent of the
changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project 5985-2009-035)
DLA - CC
Review activities:
Army - AR, AV, MI
Navy - AS, MC, OS, SH
Air Force - 99
