MIL-DTL-3922/57D
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Material: Metallic alloy as specified in table I.
Marking: See figure 1.
Part or Identifying Number (PIN): M3922/57- (and PIN from table I).
TABLE II. Cross-reference and engineering information.
PIN
AN nomenclature
Frequency range
M3922/57-
(GHz)
001
UG-407/U
3.95-5.85
002
UG-149A/U
3.95-5.85
Referenced documents. In addition to MIL-DTL-3922, this specification sheet references the following documents:
ASME B46.1
ASME-Y14.5M
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the
extent of the changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force 85
(Project 5985-2013-034)
DLA - CC
Review activities:
Army - AV, MI
Navy - AS, MC, OS, SH
Air Force - 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil/.
