MIL-DTL-3922/68A
TABLE I. Dimensions.
PIN
M3922/68-
Dimensions
Dash
Waveguide
number
used with
A
Detail
.116 DIA
M85/3-006
+.002, -.000
A
M85/3-007
001
(2.95 +.05, -.00)
M85/3-008
.112-40
M85/3-006
A
UNC-2B
M85/3-007
002
M85/3-008
.112-40
M85/3-006
B
UNC-2B
M85/3-007
003
M85/3-008
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are based upon 1 inch = 25.4 mm.
3. Millimeters are in parentheses.
REQUIREMENTS:
Dimensions and configuration: See figures 1 and 2, and table I.
Material: Copper alloy.
Part or Identifying Number (PIN): See table I.
ENGINEERING INFORMATION:
Frequency range: 26.5 - 40.0 GHz.
3
