MIL-DTL-3922/70C
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Material: Metallic alloy as specified in table I.
Marking: See figure 1.
Part or Identifying Number (PIN): M3922/70- (dash number from table I).
Cross reference and engineering information: See table II.
TABLE II. Cross reference and engineering information.
PIN M3922/70-
AN nomenclature
Frequency range
(GHz)
001
UG-1493/U
7.0 - 11.0
002, 013, 014
---
7.0 - 11.0
004, 005, 016, 017, 025, 026
---
10.0 - 15.0
007, 008, 019, 020
---
12.4 - 18.0
010, 011, 022, 023
---
15.0 - 22.0
027, 028
---
18.0 - 26.5
NOTE: Dash numbers 003, 006, 009, 012, 015, 018, 021, and 024 have been replaced by dash
numbers 002, 005, 008, 011, 014, 017, 020, and 023, respectively. A separate PIN for parts
constructed from aluminum alloy 6063 is no longer required.
