MIL-DTL-3928/17C
C
B
3
1
2
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
1.78
1.72
45.2
43.7
F
1.53
1.47
38.9
37.3
B
.135 dia
.115 dia
3.43 dia
2.92 dia
G
.135
.115
3.43
2.92
C
.25
---
6.3
---
H
8.83 dia
8.77 dia
224.3 dia
222.8 dia
D
2.50
---
63.5
---
J
6.90
6.84
175.3
173.7
E
.27
---
6.9
---
K
1.384
1.364
35.15
34.65
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 3. Switch configuration and schematic, PIN M3928/17-03.
