MIL-DTL-3970/13E
REQUIREMENTS:
Dimensions and configuration: See table I and figure 1.
Electrical characteristics: See table I.
Part or Identifying Number (PIN): M3970/13-(dash number from table I).
Cross reference: See table II.
TABLE II. Cross reference.
PIN
Type
PIN
Type
M3970/13-
designation
M3970/13-
designation
001
UG-712/U
009
UG-720/U
002
UG-713/U
010
UG-721/U
003
UG-714/U
011
UG-722/U
004
UG-715/U
012
UG-723/U
005
UG-716/U
013
UG-724/U
006
UG-717/U
014
UG-725/U
007
UG-718/U
015
UG-726/U
008
UG-719/U
016
UG-727/U
NOTE: Assemblies covered by this specification are substitutable for the following commercial types:
PIN
Manufacturer
Commercial
M3970/13-
CAGE code
type
017
10001
2938971-1
017
01456
650BH49
017
61804
L2257
031
52564
3705001
032
52564
4005001
Referenced documents. This specification sheet only references MIL-DTL-3970.
