MIL-DTL-3970/7E
REQUIREMENTS:
Dimensions and configuration: See table I and figure 1.
Electrical characteristics: See table I.
Part or Identifying Number (PIN): M3970/7-(dash number from table I).
Cross reference: See table II.
TABLE II. Cross reference.
PIN
Type
PIN
Type
M3970/7-
designation
M3970/7-
designation
001
UG-860/U
009
UG-868/U
002
UG-861/U
010
UG-869/U
003
UG-862/U
011
UG-870/U
004
UG-863/U
012
UG-871/U
005
UG-864/U
014
UG-873/U
008
UG-867/U
015
UG-874/U
NOTE: Assemblies covered by this specification are substitutable for the following commercial types:
PIN
Manufacturer
Commercial
M3970/7-
CAGE code
type
030
52564
3704001
031
52564
4004001
032
06424
1202012-1
032
00929
X623B
Referenced documents. This specification sheet only references MIL-DTL-3970.
Marginal notations are not used on this revision to identify changes with respect to the previous issue due to the
extent of the changes.
