INCH-POUNDS
MIL-DTL-4946E
5 July 2013
SUPERSEDING
MIL-DTL-4946D
8 January 2008
DETAIL SPECIFICATION
ANTENNA ASSEMBLY AT-197( )/GR
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the requirements for one type of discone antenna assembly,
designed to operate at an impedance of 50 ohms, within the frequency range of 225 through 500 megahertz
(MHz)(see 6.1).
1.2 Classification.
1.2.1 Type designation (see 6.2). The type designation of the antenna is derived from the Joint Electronic Type
Designation System specified in MIL-STD-196.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3 and 4 of this
specification, whether or not they are listed
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL STANDARDS
FED-STD-595/24084 - Green, Semigloss
DEPARTMENT OF DEFENSE SPECIFICATIONS
- Cables, Radio Frequency, Flexible, Coaxial, 50 OHMS, M17/79-RG218 Unarmored,
M17/79-RG219 Armored.
- Connectors, Coaxial, Radio Frequency, Series HN, and Associated Fittings,
General Specification for.
- Finishes for Ground Based Electronic Equipment.
Comments, suggestions or questions on this document should be addressed to DLA Land and Maritime, ATTN:
VAT, Post Office Box 3990, Columbus, OH 43218-3990, or emailed to Tubesamps@dla.mil. Since contact
information can change, you may want to verify the currency of this address information using the ASSIST
Online database at https://assist.dla.mil.
AMSC N/A
FSC 5985
