MIL-DTL-83739/1D
Dimensions
Ltr
Inches
Millimeters
Min
Max
Min
Max
A
2.57
2.69
65.3
68.3
B
.64
.70
16.3
17.8
C
---
3.44
---
87.4
D
.927
.947
23.55
24.05
E
.927
.947
23.55
24.05
F
.090
.110
2.29
2.79
G
.365
.385
9.27
9.78
H
.925
.945
23.50
24.00
J
4.13
4.19
104.9
106.4
K
.334
.354
8.48
8.99
L
.006
.026
0.15
0.66
M
2.97
3.03
75.4
77.0
N
.87
.93
22.1
23.6
P
.16
.22
4.1
5.6
Q
.97
1.03
24.6
26.2
R
1.97
2.03
50.0
51.6
S
2.47
2.53
62.7
64.3
T
3.22
3.28
81.8
83.3
U
.425
.445
10.80
11.30
V
.178
.198
4.52
5.03
W
.115
.135
2.92
3.43
X
.865
.885
21.97
22.48
Y
.615
.635
15.62
16.13
Z
.240
.260
6.10
6.60
AA
.428
.448
10.87
11.38
BB
.302
.322
7.67
8.18
CC
.190-24 UNC 2A
4.83-24 UNC-2A
DD
.312 DIA x .125
7.92 DIA x 3.18
DEEP
DEEP
EE
.190-24 UNC 2B
4.83-24 UNC-2B
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (to the nearest 0.01 mm) are given for general information only and are based upon
1 inch = 25.4 mm.
3. Unless otherwise specified, tolerances are ±.03 inch (0.76 mm) for two place decimals and ± .010 inch (0.25
mm) for three place decimals.
4. The upper and lower surface of this area is not to be painted.
5. The spring shall be strong enough to hold the bolt free when disengaged from mounting plate.
FIGURE 1. Dimensions and configuration - Continued.
