MIL-DTL-85/3D
TABLE II. Performance characteristics.
Part
frequency range
Cutoff
Theoretical attenuation (lowest
Theoretical peak power
Theoretical CW power
number
TE10 mode
for TE10 mode
to highest frequency)
rating (lowest to
rating (lowest to
M85/3-
(GHz)
(GHz)
highest frequency)
highest frequency)
(dB/100 ft)
1/
(kilowatts) 2/
(watts) 3/
006-XXX
24.55 - 16.80
103.1 - 150.1
007-XXX
26.50 - 40.00
21.10
23.02 - 15.77
96.0 - 146
109.7 - 160.1
008-XXX
---
---
009-XXX
34.46 - 23.59
73.27 - 107.0
010-XXX
34.57 - 23.50
64.73 - 95.30
011-XXX
33.00 - 50.00
26.350
32.44 - 22.05
64.4 - 97.0
68.89 - 101.4
012-XXX
---
---
013-XXX
48.53 - 32.99
46.05 - 67.74
014-XXX
42.39 - 30.46
48.30 - 67.21
015-XXX
40.00 - 60.00
31.41
39.81 - 28.60
48 - 70
51.32 - 71.43
016-XXX
---
---
017-XXX
64.23 - 43.89
28.46 - 41.44
018-XXX
50.00 - 75.00
39.90
60.25 - 41.17
30 - 40
30.27 - 44.30
020-XXX
87.79 - 58.86
19.15 - 28.56
021-XXX
60.00 - 90.00
48.40
82.37 - 55.22
20 - 30
20.37 - 30.38
023-XXX
112.5 - 79.26
13.82 - 19.63
024-XXX
75.00 - 110.00
59.06
105.6 - 74.37
14 - 20
14.73 - 20.86
026-XXX
171.4 - 110.0
8.618 - 13.43
027-XXX
90.00 - 140.00
73.84
160.9 - 103.3
8.8 - 13
9.161 - 14.27
029-XXX
238.1 - 150.9
5.662 - 8.934
030-XXX
110.00 - 170.00
90.845
223.5 - 141.7
5.9 - 9.3
6.019 - 9.494
032-XXX
343.6 - 216.0
3.674 - 5.844
033-XXX
140.00 - 220.00
115.750
322.7 - 202.8
3.7 - 6.1
3.904 - 6.211
035-XXX
428.2 - 283.2
2.832 - 4.282
036-XXX
170.00 - 260.00
137.52
402.0 - 265.9
2.8 - 4.5
3.010 - 4.551
038-XXX
570.9 - 388.0
2.021 - 2.973
039-XXX
220.00 - 325.00
173.28
536.0 - 364.4
1.9 - 2.6
2.148 - 3.159
1/ At 20°C waveguide temperature.
2/ These values were determined by calculating the non-pressurized air dielectric breakdown strength
produced by considering the E field within the waveguide. This determination was based on the peak
value of a continuous wave (CW) signal. For further information see M. Gilden and L. Gould, "Handbook
on High Power Capabilities of Waveguide Systems," June 1963, Navy Contract Nobsr-85190, Index No.
SR0080302, ST 9604.
3/ These values were determined by calculation of the rate of heat loss to the ambient, considering a non-
pressurized air dielectric waveguide in air using no artificial heat sink. A maximum waveguide
temperature of 71°C, 1:1 VSWR, and an ambient temperature of 30°C were assumed. For additional
information see H.E. King, "Rectangular Waveguide Theoretical CW Average Power Rating," IRE
Transactions PGMTT-9, pp 349-357, July 1961.
TABLE III. Supersession data and cross index.
Superseded
Cross index
Part number
part number
M85/3-
M85/1-
AN type
NATO type
EIA type
006-XXX
114-XXX
RG-96/U
NWG-6A22
WR28S
008-XXX
117-XXX
RG-271/U
---
---
010-XXX
118-XXX
RG-97/U
NWG-6A23
WR22S
012-XXX
121-XXX
RG-272/U
---
---
016-XXX
124-XXX
RG-358/U
---
---
017-XXX
125-XXX
RG-98/U
NWG-6A25
WR15S
020-XXX
129-XXX
RG-99/U
NWG-6A26
WR12S
3
