INCH-POUND
MIL-DTL-85K
2 June 2011
SUPERSEDING
MIL-DTL-85J
28 March 2006
DETAIL SPECIFICATION
WAVEGUIDES, RIGID, RECTANGULAR
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the performance requirements for seamless or fabricated rigid
waveguides with rectangular inside configurations (see 6.1).
1.2 PIN. The military PIN consists of the letter "M" followed by the basic number of the specification
sheet, an assigned dash number (see 3.1), and a coded 3-digit number indicating the length (in inches,
see 3.3.2.).
Example:
M85/1-
001-
096
Military designator
Dash number designated
Length
as specification sheet (see 3.1)
(in inches, see 3.3.2)
and specification sheet number
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
this list, document users are cautioned that they must meet all specified requirements of documents cited
in sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract.
Comments, suggestions, or questions on this document should be addressed to DLA Land and Maritime,
ATTN: VAT, P.O. Box 3990, Columbus, OH 43218-3990 or e-mailed to TubesAmps@dla.mil. Since contact
information can change, you may want to verify the currency of address information using the ASSIST Online
database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5985
