INCH-POUND
MIL-DTL-18793B
18 August 2011
SUPERSEDING
MIL-DTL-18793A
5 April 2006
DETAIL SPECIFICATION
ANTENNA AS-333/AP
Inactive for new design
after 2 February 2001.
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification establishes the requirements for antenna type AS-333/AP which is a single slot,
flush mounted, broadband airborne antenna for use over the frequency range of 420 MHz to 460 MHz.
1.2 Classification. The equipment covered by this specification is of one type and consists of the following:
Type designation
Size (inches)
Maximum allowable
Major unit
or part number
weight (pounds)
Antenna
AS-333/AP
13 x 4 x 2.75
1.5
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Cables, Radio Frequency, Flexible and Semirigid, General Specification for.
-
Treatment, Moisture- and Fungus-Resistant, of Communications, Electronic, and
Associated Electrical Equipment (Inactive for new design).
Electronic Equipment, Aerospace, General Specifications for (Inactive for new
-
design).
-
Design Examinations, Engineering Avionic Systems/Equipment, General Specification
for.
Nomenclature and Identification for Aeronautical Systems Including Joint Electronics
Type Designated Systems and Associated Support Systems.
Connectors, Coaxial, Radio Frequency, General Specification for.
Comments, suggestions or questions on this document should be addressed to DLA Land and Maritime, ATTN: VAT,
Post Office Box 3990, Columbus, OH 43218-3990, or emailed to TubesAmps@dla.mil. Since contact information can
change, you may want to verify the currency of this address information using the ASSIST Online database at
AMSC N/A
FSC 5985
