MIL-DTL-23971/1B
Dimensions
Inches
Millimeters
Max
Min
Max
Min
A
1.27
1.23
32.3
31.2
B
1.020
1.000
25.91
25.40
C
.981
.951
24.92
24.16
D
.347
.327
8.81
8.31
E
.17
.11
4.3
2.8
F
.25
.15
6.4
3.8
G
.130
.110
3.30
2.79
H
.240 dia
N/A
6.10 dia
N/A
J
.110 dia
.90 dia
2.79 dia
22.9 dia
K
.0505
.0495
1.28
1.26
L
.684
.664
17.4
16.9
M
.12
N/A
3.0
N/A
N
.025
N/A
.64
N/A
P
.095
.065
2.4
1.7
Q
1.27
1.23
32.3
31.2
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.010 (.25 mm) for three place decimals and
±.02 (.5 mm) for two place decimals.
FIGURE 1. Dimensions and configuration, P/N 001 and 002 - Continued.
2
