MIL-DTL-23971/16A

Inches

.01

0.3

.14

3.6

.50

12.7

1.23

31.2

.02

0.5

.19

4.8

.60

15.2

1.73

43.9

.03

0.8

.25

6.4

.69

17.5

2.12

53.8

.04

1.0

.40

10.2

.85

21.6

2.50

63.5

.05

1.3

.42

10.7

.87

22.1

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

FIGURE 7. Dimensions and configurations, 6-way, dash number 15.
