MIL-DTL-24215/10B
REQUIREMENTS
Dimensions and configuration: See figure 1 and table I.
Voltage standing wave ratio (VSWR): 1.4:1 maximum.
Attenuation range: 0 to 101 dB in 1 dB steps.
Attenuation accuracy: ± 2 dB or 2 percent of indicated dB, whichever is less.
Operating ambient temperature. 0°C to +65°C.
Part number: See figure 1 and table I.
TABLE I. Electrical requirements.
Part
Operating
Insertion
Nominal
Input
number
frequency
loss
impedance
power
M24215/10-
(GHz)
(max)
(ohms)
(max)
001
DC-1
0.6 dB
50
1.0 watt
002
DC-0.5
0.2 dB
75
0.5 watt
Referenced documents. In addition to MIL-DTL-24215, this document references the following:
MIL-PRF-39012/16
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the
extent of the changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
DLA - CC
Review activities:
(Project 5985-2012-005)
Army - AR, MI
Navy - AS, MC, OS, SH
Air Force - 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil/.
.
