MIL-DTL-24215/9C
NOTES:
Inches
Millimeters
1. Dimensions are in inches.
Max
Min
Max
Min
2. Metric equivalents are given for general
A
2.28
2.22
57.9
56.4
information only.
B
1.22
1.16
31.0
29.5
3. Unless otherwise specified, tolerance is
C
.12
.06
3.0
1.5
±.03 (.8 mm).
D
2.192
2.182
55.7
55.4
E
.133 dia
.127 dia
3.38 dia 3.23 dia
F
2.067
2.057
52.5
52.2
G
.12
.07
3.0
1.8
H
.65
.59
16.5
15.0
J
.94
.88
23.9
22.4
K
.41
.35
10.4
8.9
L
2.41
2.35
61.2
59.7
FIGURE 5. Dimensions and configuration for part number M24215/9-005
7
