MIL-DTL-25879G
3.6 Marking (see 3.1). Switches shall be marked in a legible and permanent manner with the following information.
a.
The RF connections shall be identified as shown on figure 1.
b.
Minimum marking shall include the following:
(1)
Name: Switch, RF transmission line.
(a)
Part or Identifying Number (PIN): Type SA-521A/A.
(b)
Voltage: 28 V dc maximum.
(c)
Contract number: As assigned by acquiring agency.
(d) Manufacturer CAGE code.
The marking shall remain legible after completing all environmental tests.
3.7 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or environmentally
preferable materials should be used to the maximum extent possible, provided that the material meets or exceeds the
operational and maintenance requirements, and promotes economically advantageous life cycle costs.
3.8 Workmanship. Switches shall be manufactured and processed in a careful and workmanlike manner, in
accordance with good design and sound engineering practice, and to the requirements of this specification. For
guidance on workmanship see 6.7.
4. VERIFICATION
4.1 Classification of inspections. The inspections specified herein are classified as follows:
a.
Materials inspection (see 4.2).
b.
First article inspection (see 4.4).
Conformance inspection (see 4.5).
c.
4.2 Materials inspection. Materials inspection shall consist of certification supported by verifying data (see 6.3)
that the materials listed in table I, used in fabricating the switches, are in accordance with the applicable
specifications or requirements prior to such fabrication.
TABLE I. Materials inspection.
Material
Requirement
paragraph
Dissimilar metals - - - -- - - -
Fungus - - - - - - - - - - - - -
Finish- - - - - - - - - - - - - -
Connectors - - - - - - - - - - -
3.2.6
4.3 Inspection conditions. Unless otherwise specified herein, all inspections shall be performed in accordance with
the test conditions specified in the "GENERAL REQUIREMENTS" of MIL-STD-202.
4.4 First article inspection (see 3.1). First article inspection shall be performed at a laboratory acceptable to the
Government (see 6.3) on sample units produced with equipment and procedures normally used in production.
7
