INCH-POUND
MIL-DTL-39030/11A
14 April 2003
SUPERSEDING
MIL-D-39030/11
22 December 1990
DETAIL SPECIFICATION SHEET
DUMMY LOAD, ELECTRICAL, COAXIAL,
TYPE V (N), HIGH POWER
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification and MIL-DTL-39030.
Dash
A
B
number
4.61
1.63
01
±.06
±.03
5.06
1.63
02
Inches
mm
±.03
±.03
.8
.03
1.5
.06
41.4
1.63
117.1
4.61
128.5
5.06
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Part or Identifying Number (PIN).
FIGURE 1. Dimensions and configuration, PINs M39030/11-01 and -02.
AMSC N/A
1 of 5
FSC 5985
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
