MIL-DTL-3922/52D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (to the nearest .01 mm) are given for general information only and are based
on 1.00 inch = 25.4 mm.
3. One seal is to be supplied with each grooved flange.
Inches
mm
Inches
mm
.003
0.08
.125
3.18
.005
0.13
.164
4.17
.010
0.25
.190
4.83
.015
0.38
.203
5.16
.030
0.76
.250
6.35
.031
0.79
.3125
7.94
.040
1.02
.625
15.88
.047
1.19
.75
19.05
.062
1.57
1.0
25.40
.078
1.98
1.5
38.10
FIGURE 2. Grooved flange seal.
5
