MIL-DTL-3922/52D
REQUIREMENTS:
Dimensions and configuration:
Flange: See figure 1 and table I.
Gasket: See figure 2.
Material: Flange: Metallic base alloy as specified in table I.
Items supplied with flanges: See table III.
Marking: See figure 1.
Part or Identifying Number (PIN): M3922/52- (and dash number from table I.)
AN nomenclature and engineering data: See table IV.
Minimum pressure applied shall be 120 Kilopascal (KPa).
TABLE III. Items supplied with flange.
PIN 1/
Spring
Quantity
M3922/52-
Hexagon head cap screw
Hexagon nut
lockwasher
(each)
(5/16) .3125-18 UNC-2A,
001, 002,
(5/16) .3125-18 UNC-2B
.3125 x .078
5
1.5 inch long
023, 024
003, 004, 005,
(1/4) .250-20 UNC-2A,
(1/4) .250-20 UNC-2B
.250 x .062
5
006, 007, 008,
1.5 inch long
025, 026, 027,
028, 029, 030
009, 010, 011,
(1/4) .250-20 UNC-2A,
(1/4) .250-20 UNC-2B
.250 x .062
5
012, 031, 032,
1.0 inch long
033, 034
013, 014, 015,
(1/4) .250-20 UNC-2A,
(1/4) .250-20 UNC-2B
.250 x .062
4
016, 035, 036,
1.0 inch long
037, 038
017, 018,
(No. 10) .190-32 UNF-2A,
(No. 10) .190-32 UNF-2B
.190 x .047
4
039, 040
.750 inch long
019, 020, 021,
(No. 8) .164-32 UNC-2A,
(No. 8) .164-32 UNC-2B
.164 x .040
4
022, 041, 042,
.750 inch long
043, 044
1/ One gasket (see figure 2) shall be supplied with each PIN 023 through 044.
7
