MIL-DTL-3928/11D
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.354
.334
8.99
8.48
G
.65
.59
16.5
15.0
B
.560
.540
14.22
13.72
H
1.34
1.28
34.0
32.5
C
.110
.090
2.79
2.29
J
.110
.090
2.79
2.29
D
.59
.53
15.0
13.5
K
.143 dia
.137 dia
3.63 dia
3.48 dia
E
1.747
1.727
44.37
43.87
L
.78
.72
19.8
18.3
F
1.947
1.927
49.45
48.95
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 2.54 mm).
3. Metric equivalents are in parentheses.
4. Corners of case may be round or square.
5. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
FIGURE 1. PIN M3928/11-01 - Continued.
2
