MIL-DTL-3928/11D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
RF connectors: Female connectors shall mate with type BNC male connectors in accordance with MIL-PRF-
39012/16.
Nominal impedance: 50 ohms.
Termination: Open.
RF power handling capability (average): 100 watts.
Electrical and performance characteristics: See table I.
Vibration: Method I.
Operating temperature: -55 °C to +85 °C.
Part or Identifying Number (PIN): M3928/11- 01N.
TABLE II. PIN to type cross-reference.
PIN
Type SA-
/U
M3928/11-
01
1501
Referenced documents: In addition to MIL-DTL-3928, this document references the following:
MIL-PRF-39012/16
