MIL-DTL-3928/21E
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
2.19
2.13
55.6
54.1
L
.22
.16
5.6
4.1
B
.646
.626
16.41
15.90
M
.720
---
18.29
---
C
.066
.060
1.68
1.52
N
2.15
---
54.6
---
D
1.37
---
34.8
---
P
.553
.537
14.05
13.64
E
.646
.626
16.41
15.90
Q
1.790
1.770
45.47
44.96
F
1.30
---
33.0
---
R
.300
---
7.62
---
G
.015
---
0.38
---
S
.159 dia
.139 dia
4.04 dia
3.53 dia
H
1.098
1.082
27.89
27.48
T
.35
.29
8.9
7.4
J
.53
.47
13.5
11.9
U
.65
.59
16.5
15.0
K
.28
.22
7.1
5.6
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 1. PIN M3928/21-01 - Continued.
