MIL-DTL-3928/21E
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
3.28
3.22
83.3
81.8
J
.32
---
8.1
---
B
1.80
---
45.7
---
K
2.60
---
66.0
---
C
.09
---
2.3
---
L
.78
.72
19.8
18.3
D
2.610
2.590
66.29
65.79
M
.65
---
16.5
---
E
1.510
1.490
38.35
37.85
N
.885
.865
22.48
21.97
F
.63
.57
16.0
14.5
P
.452
.432
11.48
10.97
G
.33
.27
8.4
6.9
Q
.895
.875
22.73
22.23
H
.28
.22
7.1
5.6
R
.198
.192
5.03
4.88
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only (1.00 inch = 25.4 mm).
3. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
4. Round corners of case may be squared.
FIGURE 3. PIN M3928/21-03.
4
