MIL-DTL-3933/10G
ENGINEERING DATA:
Operating frequency range: DC to 18 gigahertz (GHz) (see table I).
Test frequency range for VSWR and attenuation measurements, measured or recorded, when using an Automatic
Network Analyzer (ANA) or equivalent test equipment:
100 MHz (or lower) to
Dash numbers
4 GHz
01 through 05
8 GHz
06 through 10
11 GHz
11 through 15
18 GHz
16 through 22
Basic test frequency for sensitive measurements like connector repeatability, temperature sensitivity, power
sensitivity, and any other measurements where a `delta' specification is imposed:
Basic test frequency
Dash numbers
2 GHz
01 through 05
4 GHz
06 through 10
6 GHz
11 through 15
8 GHz
16 through 22
Operating temperature range:
-55°C to +85°C.
M3933/10-1:
M3933/10-2 through -22: -55°C to +125°C.
Maximum weight: 6 ounces.
REQUIREMENTS:
Dimensions and configuration: See figures 1 and 2. Cooling fins shall be circular.
Nominal impedance: 50 ohms.
Attenuation: See table I. Stability and sensitivity:
Maximum attenuation change after:
Up to 10 dB, inclusive (dB)
Over 10 dB (dB/dB)
Temperature change/ thermal shock
0.05
0.005
Vibration or shock
0.1
0.01
Moisture resistance or salt spray
0.2
0.02
Peak power
0.05
0.005
Frequency sensitivity, maximum:
0.1 dB/dB/GHz.
Temperature sensitivity of attenuation, maximum: 0.0004 dB/dB/°C.
Power: See table I.
Power sensitivity for full input power, maximum:
0.005 dB/dB/Watt.
VSWR: See table I.
Connector repeatability, maximum variation in attenuation: 0.02 dB.
Part or Identifying Number (PIN): M3933/10- (and dash number from table I).
Part or Identifying Number (PIN): M3933/10- (and dash number from table I with three device level
designators are space level (T), screened (S) and non-screened (N) options)
