INCH-POUND
MIL-DTL-55041/10B
27 July 2010
SUPERSEDING
MIL-DTL-55041/10A
2 February 2000
DETAIL SPECIFICATION SHEET
SWITCH, WAVEGUIDE, ELECTROMECHANICAL, LATCHING,
FREQUENCY RANGE 8.6 TO 10.3 GHz
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the switch described herein
shall consist of this specification sheet and MIL-DTL-55041.
Dimensions
Lt
Inches
Millimeters
r
Min
Max
Min
Max
A
.53
.83
13.46
21.08
B
2.22
2.58
56.39
65.53
square
square
square
square
C
4.50
5.50
114.30
139.70
D
2.43
2.60
61.72
66.04
E
---
1.250
---
31.75
F
---
2.000
---
50.80
G
---
1.000
---
25.40
H
---
1.000
---
25.40
J
---
1.750
---
44.45
K
.190-32 UNF-2B
4.83-32 UNF-2B
Hole depth .370 Min
Hole depth 9.40 Min
L
1.794
1.806
45.57
45.87
FIGURE 1. Switch configuration and schematic,
M
---
2.62
---
66.55
PIN M55041/10-001.
square
square
N
.164-32 UNC-2B
4.17-32 UNC-2B
Full thread depth .370 Min
Full thread depth 9.40 Min
AMSC N/A
FSC 5985
