MIL-DTL-55041/11A
REQUIREMENTS:
Design and construction:
Dimensions and configuration: See figure 1, figure 2, and table I.
Power connectors: See figure 1 and figure 2.
Operation: Break before make.
Operating temperature range: -54°C to +95°C.
Electrical performance characteristics: See table II.
Part or identifying number (PIN): M55041/11- (and dash number from tables I and II).
Substitutability data: The switches covered by this specification sheet are substitutable for the user's or
manufacturer's PIN specified in table III. This information in no way implies that the manufacturer's PIN or NSN is
suitable as a substitute for the military PIN.
TABLE III. Substitutability data.
Dash number
Manufacturer's code
Commercial type
NSN 5985-
001
00471
33D08400
01-073-1529
002
00471
33D06400
01-235-7794
003
00471
33D04400
01-233-2561
004
81755
654VE4826-3
01-099-6113
004
00471
33D03400
01-099-6113
005
81755
C4715-1
00-009-3159
005
00471
33D00400
00-009-3159
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5985-2006-021)
DLA - CC
Review activities:
Army - SM, MI
Navy - AS, MC, OS, SH
Air Force - 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil.
6
