MIL-F-3922/58D
REQUIREMENTS:
Dimensions and configuration:
Flange See figure 1 and table I.
Gasket See figure 2 and table II.
Material:
Flange Metallic base alloy as specified in table I.
Marking: See figure 1.
Part number M3922/58 (and dash number from table I).
Items supplied with flange: See table III.
AN nomenclature and engineering data: See table IV.
TABLE IV. Cross- reference of part numbers /AN nomenclature and engineering data.
Part No. M3933/58-
AN nomenclature
Frequency range
GHz
007
UG-417B/U
1.12 1.70
008
UG-418B/U
1.12 1.70
009
UG-435B/U
1.70 2.60
010
UG-437B/U
1.70 2.60
011
UG-553A/U
2.20 3.30
012
UG-554A/U
2.20 3.30
Referenced documents. In addition to MIL-DTL-3922 this specification sheet references the following documents:
ASME-B46.1
SAE-AMS-QQ-S-763
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the
extent of the changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project 5985-2013-044)
DLA - CC
Review activities:
Army - AV, MI
Navy - AS, CG, MC, OS, SH
Air Force - 19, 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil/.
