MIL-DTL-23971/6C
Inches
mm
Inches
mm
.009
0.23
.11
2.8
.016
0.41
.19
4.8
.019
0.48
.21
5.3
.028
0.71
.32
8.1
.034
0.86
.40
10.2
.09
2.3
.53
13.5
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are based upon 1.00 inch = 25.4 mm.
3. Ground pins are grounded to the internal circuit of the power divider, by the manufacturer.
FIGURE 4. Dimensions and configuration, 3-way, dash number 08.
4
