MIL-DTL-23971D
TABLE V. Group B inspection.
Inspection
Requirement
Test method
paragraph
paragraph
Power level- - - - - - - - - -- - - - - - - - - - - - - - - - -
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Insertion loss - - - - - - - - - - - - - - - - - - - - - - -
Isolation - - - - - - - - - - - - - - -- - - - - - - - - - - -
Electromagnetic interference 1/ - - - - - - - - - - -
Thermal shock- - - - - - - - - - - - - - - - - - - - - - - -
3.6.3
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Insertion loss - - - - - - - - - - - - - - - - - - - - - - -
Isolation - - - - - - - - - - - - - - -- - - - - - - - - - - -
Terminal strength 4/ - - - - - - - - - - - - - - - - - - - -
Resistance to solvents - - - - - - - - - - - - - - - - - -
Solderability 5/ - - - - - - - - - - - - - - - - - - - - - - -
Vibration - - - - - - - - - - - - - - - - - - - - - - - - - - - -
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Insertion loss - - - - - - - - - - - - - - - - - - - - - - -
Isolation - - - - - - - - - - - - - - -- - - - - - - - - - - -
Phase balance - - - - - - - - - - - - - - - - - - - - - -
Amplitude balance - - - - - - - - - - - - - - - - - - -
Shock - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Insertion loss - - - - - - - - - - - - - - - - - - - - - - -
Isolation - - - - - - - - - - - - - - -- - - - - - - - - - - -
Phase balance - - - - - - - - - - - - - - - - - - - - - -
Amplitude balance - - - - - - - - - - - - - - - - - - -
Moisture resistance 2/ - - - - - - - - - - - - - - - - - -
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Insertion loss - - - - - - - - - - - - - - - - - - - - - - -
Isolation - - - - - - - - - - - - - - -- - - - - - - - - - - -
Phase balance - - - - - - - - - - - - - - - - - - - - - -
Amplitude balance - - - - - - - - - - - - - - - - - - -
Salt atmosphere 3/ - - - - - - - - - - - - - - - -
1/ When specified.
2/ Applicable to enclosed type and immersion proof only.
3/ Applicable to hermetic seal and immersion proof only.
4/ Applicable to plug-in and solder terminals.
5/ Applicable to items with solder terminals.
4.6.1.3.1 Group B Sampling plan. Statistical sampling and inspection shall be performed on an inspection lot basis
with a random sample of components selected in accordance with table VI. Acceptance shall be based upon the
zero defective sampling plan. No failures shall be permitted. Sample sizes are for standard Military component
reliability and for higher level reliability (intended for space flight applications).
TABLE VI. Group B sampling plan.
Lot size
Sample size (Standard Military)
"Space Flight Application"
power divider sample size
2-25
1
2
26-150
2
4
151-10,000
4
8
11
