INCH-POUND
MIL-DTL-24215D
14 December 2010
SUPERSEDING
MIL-DTL-24215C
16 January 2007
DETAIL SPECIFICATION
ATTENUATORS, VARIABLE (COAXIAL),
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers variable continuously and variable in steps attenuators for use as
attenuating elements in coaxial lines. These attenuators are used for armed services application in the
transmission lines of radar, radio, and associated equipment (see 6.1).
Class
Type of RF connector
Connector specification
5
SMA
7
BNC
1.3 Part or Identifying Number (PIN). The PIN consists of the letter "M", the basic number of the
specification sheet, and an assigned dash number as shown in the following example (see 3.1):
M24215/
9
001
Military designator
Slash sheet
Dash number designated
and specification
number
on specification sheet
number
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 or 4 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
this list, document users are cautioned that they must meet all specified requirements documents cited in
sections 3 or 4 of this specification, whether or not they are listed.
Comments, suggestions, or questions on this document should be addressed to DLA Land and
Maritime, ATTN: - VAT, Post Office Box 3990, Columbus, OH 43218-3990 or emailed to
TubesAmps@dscc.dla.mil. Since contact information can change, you may want to verify the
currency of this address information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5985
