INCH-POUND
MIL-DTL-25707F
16 April 2008
SUPERSEDING
MIL-DTL-25707E
23 July 1999
DETAIL SPECIFICATION
ANTENNA, FLUSH MOUNT, L-BAND,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Depart-
ments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This document covers the general requirements for flush mounted L-band antennas within the frequency range of
960 to 1,220 MHz.
1.2 Classification. Antennas covered by this document are classified by style, as specified (see 3.1).
1.3 Part or Identifying Number (PIN). The PIN consists of the letter M, the basic number of the specification sheet, and an
assigned dash number (see 3.1) as shown in the following:
M25707/1 -01
Military designator___________
_____Dash number
Specification sheet number _
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This section does not
include documents cited in other sections of this specification or recommended for additional information or as examples. While
every effort has been made to ensure the completeness of this list, document users are cautioned that they must meet all specified
requirements documents cited in sections 3, 4, or 5 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a part of this
document to the extent specified herein. Unless otherwise specified, issues of these documents are those cited in the solicitation
or contract (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATIONS
MIL-DTL-3643
-
Connectors, Coaxial, Radio Frequency, Series HN, and Associated Fittings, General
Specification for.
MIL-PRF-5606
-
Hydraulic Fluid, Petroleum Base; Aircraft, Missile, and Ordnance.
MIL-DTL-5624
-
Turbine Fuel, Aviation, Grades JP-4, JP-5, and JP-5/JP-8ST.
MIL-PRF-39012
-
Connectors, Coaxial, Radio Frequency: General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-810
-
Test Methods Standard for Environmental and Engineering Considerations and
Laboratory Tests.
MIL-STD-1285
-
Marking of Electrical and Electronic Parts.
Comments, suggestions, or questions on this document should be addressed to: Commander, Defense Supply Center Columbus, ATTN:
DSCC-VAT, P.O. Box 3990, Columbus, OH 43218-3990, or e-mailed to TubesAmps@dla.mil. Since contact information can change, you
may want to verify the currency of this address information using the ASSIST Online database at https://assist.daps.dla.mil/.
AMSC N/A
FSC 5985
