MIL-DTL-25707F
4.4.1.2 Group A inspection. Group A inspection shall consist of the inspections specified in table II, in the order shown.
TABLE II. Group A inspection.
Inspection
Requirement
Test method
paragraph
paragraph
Visual and mechanical inspection
Materials- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Physical dimensions - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Marking - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Workmanship - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Sampling probe VSWR - - - - - - - - - - - - - - - - - - - - - - - - - - -
Sampling probe attenuation - - - - - - - - - - - - - - - - - - - - - - - -
4.4.1.2.1 Group A sampling plan. Statistical sampling and inspection shall be performed on an inspection lot basis (see 4.4.1.1)
with a random sample of antennas selected in accordance with table III. The acceptance levels shall be based upon the zero
defective sampling plan. No failures shall be permitted.
TABLE III. Group A sampling plan.
Lot size
Sample size
1 - 13
100 percent
14 - 150
13
151 - 280
20
281 - 500
29
501 - 1,200
34
1,201 - 3,200
42
3,201 - 10,000
50
10,001 - 35,000
60
35,001 - 150,000
74
150,001 - 500,000
90
500,001 and over
102
4.4.1.2.2 Rejected lots. If an inspection lot is rejected, the contractor may rework it to correct the defects, or screen out the
defective units and resubmit for reinspection. Resubmitted lots shall be inspected using tightened inspection. Such lots shall be
separated from new lots and shall be clearly identified as reinspected lots.
4.4.2 Periodic inspection. Periodic inspection shall consist of group B. Except where the results of these inspections show
noncompliance with the applicable requirements (see 4.4.2.1.2), delivery of products which have passed group A shall not be
delayed pending the results of these periodic inspections.
4.4.2.1 Group B inspection. For individual procurements involving small quantities of antennas, Group B testing shall be at the
option of the acquiring activity (see 6.4) and of the procurement contract (see 6.2). Group B inspection shall consist of the tests
specified in table IV, in the order shown. Group B inspection shall be made on one sample unit per contract, unless otherwise
specified, which has been subjected to and passed group A inspection.
