MIL-DTL-39030/3E
Inches
mm
Dash
A
.005
0.13
number
max
.01
0.3
.26
6.6
-09, -20
.84
.312
7.92
-10, -21
.55
.33
8.4
-12, -23
.55
.55
14.0
.84
21.3
-14, -25
.55
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Series SMA pin contact interface in accordance with MIL-STD-348.
FIGURE 5. Dimensions and configuration, PINs M39030/3-09, -10, -12, -14, -20, -21, -23, and -25 (both N and S).
