MIL-DTL-3922/54E
REQUIREMENTS:
Dimensions and configuration: See figures 1 and 2 and tables I and II.
Material: Metallic alloy as specified in tables I and II.
Marking: See figures 1 and 2.
PIN: M3922/54- (and dash number from tables I and II).
TABLE III. Cross-reference and engineering information.
PIN
Frequency range
M3922/54-
AN nomenclature
(GHz)
001
UG-595/U
18.0 - 26.5
002
UG-597/U
18.0 - 26.5
003
UG-599/U
26.5 - 40.0
005
---
7.05 - 10.00
006
---
7.05 - 10.00
007
---
8.20 - 12.40
008
---
8.20 - 12.40
009
---
12.40 - 18.00
010
---
12.40 - 18.00
011
---
7.05 - 10.00
012
---
7.05 - 10.00
013
---
8.20 - 12.40
014
---
8.20 - 12.40
015
---
12.40 - 18.00
016
---
12.40 - 18.00
Part M3922/54-004 has been canceled.
Referenced documents. In addition to MIL-DTL-3922, this specification sheet references the following documents:
ASME-B46.1
ASME-Y14.5M
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the
extent of the changes.
