MIL-DTL-3922/59F
REQUIREMENTS:
Dimensions and configuration:
Flange: See figure 1 and table I.
Gasket: See figure 2 and table II.
Material: Metallic alloy as specified in table I.
Marking: See figure 1.
Part or Identifying Number (PIN): M3922/59- (and dash number from table I).
Materials supplied with flange: See table III.
TABLE IV. Cross reference and engineering information.
PIN M3922/59-
AN nomenclature
Frequency range
(GHz)
001
UG-541A/U
12.4 - 18.0
002
UG-1666/U
12.4 - 18.0
003
UG-596A/U
18.0 - 26.5
004
UG-598A/U
18.0 - 26.5
005
UG-600A/U
26.5 - 40.0
006
UG-40B/U
8.20 - 12.4
007
UG-52B/U
7.05 - 10.0
008
UG-136B/U
8.20 - 12.4
009
UG-137B/U
7.05 - 10.0
010
---
10.0 - 15.0
011
---
10.0 - 15.0
012
---
26.5 - 40.0
013
---
8.20 - 12.4
014
---
8.20 - 12.4
015
---
7.05 - 10.0
016
---
7.05 - 10.0
Referenced documents. In addition to MIL-DTL-3922, this specification sheet references the following documents:
ASME-B46.1
Marginal notations are not used in this revision to identify changes with respect to the previous issue due to the extent of the
changes.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 85
(Project 5985-2009-037)
DLA - CC
Review activities:
Army - AR, AV, MI
Navy - AS, MC, OS, SH
Air Force - 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since organizations and
responsibilities can change, you should verify the currency of the information above using the ASSIST Online database at
