MIL-DTL-3922/59F
FIGURE 2. Gasket.
TABLE II. Gasket dimensions.
Dimensions 1/ 2/
Former
DIM
Inches
Millimeters
Gasket U/W
MS PIN
Min
Max
Min
Max
M3922/59-
A
.915
.927
23.24
23.55
001 and
MS90064-12
B
.136
.142
3.45
3.61
002
A
.565
.585
14.35
14.86
004 and
MS90064-11
B
.057
.063
1.45
1.60
003
A
.421
.431
10.69
10.95
005 and
MS90064-10
B
.067
.073
1.70
1.85
012
A
1.333
1.343
33.86
34.11
006, 008,
MS90064-13
B
.089
.095
2.26
2.41
013, 014
A
1.545
1.555
39.24
39.50
007, 009,
MS90064-14
B
.089
.095
2.26
2.41
015, 016
A
1.108
1.120
28.14
28.45
010 and
B
.067
.073
1.70
1.85
011
1/ Dimensions are in inches.
2/ Metric equivalents (to the nearest .01 mm) are given for general information only and are based upon
1.00 inch = 25.4 mm.
TABLE III. Materials supplied with flanges.
Item
M3922/59-001, -002,
M3922/59-003, -004,
M3922/59-006, -007,
Quantity
-010, and -011
-005, and -012
-008, -009, -013, -014,
-015, and -016
Gasket - - - - - - - - - - - - - -
Silicon rubber
Silicon rubber
Silicon rubber
1
(see figure 2)
(see figure 2)
(see figure 2)
Socket-head cap screw - -
.138-32 UNC-2A,
.112-40 UNC-2A,
.164-32 UNC-2A,
4
.375 (9.53 mm) long, -001, -002)
.375 (9.53 mm) long
.375 (9.53 mm) long
.500 (12.70 mm) long, -010, -011)
Lockwasher - - - - - - - - - -
#8-.031 (0.79 mm) thick
4
#6-.031 (0.79 mm) thick
#4-.022 (0.56 mm) thick
9
