MIL-DTL-55288 Antenna As-1729/VrcThis specification covers one type of center-fed whip antenna intended for use in a vehicular communications system operating over the frequency range of 30.00 to 76.00 MHz and designated as Antenna AS-1729/VRC \(see 6.1 and 6.6\). The antenna consists of the following units: Antenna Element AT-1095/VRC \(Upper Whip Section\). Antenna Element, AS-1730/VRC \(Lower Whip Section\). Matching Unit-Base, Antenna MX-6707/VRC \(Base Assembly\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21


. . . . . . . . . . . . . . . . . . . .
MIL-DTL-55288E
TABLE V. Order of environmental tests.
Test
Unit 1
Unit 2
Unit 3
Unit 4
Non-damaging tests
1
Temperature (see 4.7.1)
1
Immersion (see 4.7.3)
Potentially damaging tests
Impact (see 4.7.7)
2
2
Flexing (spring) (see 4.7.8)
3
Vibration (see 4.7.4)
3
1
Bounce (see 4.7.5)
4
Shock, ballistic (see 4.7.6)
5
Rain (see 4.7.11)
6
Humidity (see 4.7.2)
4
Fungus (see 4.7.9) 1/
1
Salt fog (see 4.7.10) 1/
2
1/ The equipment shall be thoroughly washed, cleaned, dried and refurbished, if necessary, before proceeding
with subsequent tests.
4.4 Inspections covered by subsidiary documents. The following shall be inspected under the applicable
subsidiary documents as part of the inspection of equipment before packaging:
Item
Paragraph
Part, materials and processes
Castings
Marking
4.5 Conformance inspection of equipment before packaging. Each unit of each lot of equipment shall be subjected
to bounce preconditioning (see 3.9) prior to inspection. The contractor shall perform the inspection specified in 4.4
and 4.5.1 through 4.5.3.2. This does not relieve the contractor of his responsibility for performing any additional
inspection which is necessary to control the quality of the product and to assure compliance with all specification
requirements. Failure to meet any requirement as a result of bounce precondition shall be classified as a defect and
recorded as such. The Government will review and evaluate the contractor's inspection procedure and examine the
contractor's inspection records. In addition, the Government, at its discretion, may perform all or any part of the
specified inspection to verify the contractor's compliance with specified requirements (see 6.7). Test equipment for
Government verification inspection shall be made available by the contractor. Each unit which will be subjected to
group A, group B, group C, or first article inspection shall be preconditioned after final assembly (see 4.6).
