MIL-DTL-55288 Antenna As-1729/VrcThis specification covers one type of center-fed whip antenna intended for use in a vehicular communications system operating over the frequency range of 30.00 to 76.00 MHz and designated as Antenna AS-1729/VRC \(see 6.1 and 6.6\). The antenna consists of the following units: Antenna Element AT-1095/VRC \(Upper Whip Section\). Antenna Element, AS-1730/VRC \(Lower Whip Section\). Matching Unit-Base, Antenna MX-6707/VRC \(Base Assembly\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21


. . . . . . . . . . . . . . . . . . . . . . .
MIL-DTL-55288E
4.5.1 Group A inspection. Each unit of each lot of equipment shall be inspected for conformance to all the
inspection and test requirements of table VI. Group A inspection shall be performed in any order which is satisfactory
to the Government, except that the air seal (see 4.9) shall be last.
TABLE VI. Group A inspection.
Requirement
Inspection
Inspection
paragraph
paragraph
Visual and mechanical:
Antenna Element AT-1095/VRC
Antenna Element AS-1730/VRC
Matching Unit-Base, Antenna MX-6707/VRC
Antenna AS-1729/VRC
Electrical:
Matching Unit-Base, Antenna MX6707/VRC
Base Assembly Resonance
Control Cable Voltage
Antenna Whip Elements
Top Whip Section
Lower Whip Section
Whip Assembly
Matching Unit-Base, Antenna MX-6707/VRC
Air Seal
4.5.2 Group B inspection. Group B inspection shall be performed on lots that have passed group A inspection.
This inspection shall consist of the inspections listed in table VII. Each lot shall be subjected to sampling inspections
in accordance with table VIII. Lots in which samples exhibit any failures shall be screened for that failure prior to units
within the lot being subjected to group C inspection.
4.5.2.1 Order of inspection within group B. Group B inspection shall be performed in any order which is
satisfactory to the Government.
TABLE VII. Group B inspection.
Requirement
Inspection
Inspection
paragraph
paragraph
Electrical
Antenna Element AS-1730/VRC
X-ray
Antenna AS-1729/VRC
Immersion
Interchangeability
11
