INCH-POUND
MIL-DTL-3928/10F
28 January 2013
SUPERSEDING
MIL-DTL-3928/10E
15 August 2001
DETAIL SPECIFICATION SHEET
SWITCHES, RADIO-FREQUENCY TRANSMISSION LINE
(COAXIAL) (ELECTRICALLY OPERATED) CLASS 1
This specification is approved for use by all Departments and
Agencies of the Department of Defense.
Requirements for acquiring the switch described herein
shall consist of this specification and MIL-DTL-3928.
Position 1. (De-energized or failsafe position),
C connects to NC connector.
Position 2. (Energized position),
C connects to NO connector.
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
2.03
1.97
51.6
50.0
J
1.510
1.490
38.35
37.85
B
1.135
1.115
28.83
28.32
K
.792
.772
20.12
19.61
C
.112-40 UNC-2B dia
2.84-40 UNC-2B dia
L
.604
.584
15.34
14.83
D
.697
.677
17.70
17.20
M
.681
.661
17.30
16.79
E
.104
.084
2.64
2.13
N
1.03
.97
26.2
24.6
F
.885
.865
22.48
21.97
P
.775
.755
19.68
19.18
G
.135
.115
3.43
2.92
Q
.510
.490
12.95
12.45
H
.510
.490
12.95
12.45
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents (in millimeters) are given for general information only (1.00 inch = 25.4 mm).
3.
Corners of case may be round or square.
4.
Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
FIGURE 1. PINs M3928/10-01, M3928/10-02, and M3928/10-03.
AMSC N/A
FSC 5985
