MIL-DTL-3928/10F
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
2.00
---
50.8
---
M
.40
.33
10.2
8.4
B
1.10
.90
27.9
22.9
N
.37
.31
9.4
7.9
C
.107
.097
2.72
2.46
P
.185 dia
.175 dia
4.70 dia
4.45 dia
D
1.10
.90
27.9
22.9
Q
1.567
1.557
39.80
39.55
E
2.00
---
50.8
---
R
2.255
2.245
57.28
57.02
F
1.03
.97
26.2
24.6
S
1.010 ref
.990 ref
25.65 ref
25.15 ref
G
3.28
3.22
83.3
81.8
T
.164-32 UNC-2B
4.17-32 UNC-2B
x .37 DP
(No. 8)
x 9.40 DP
(No. 8)
H
.69
.63
17.5
16.0
J
4.40
---
111.8
---
U
.817
.807
20.75
20.50
K
2.78
2.72
70.6
69.1
V
1.03
.97
26.2
24.6
L
2.40
2.34
61.0
59.4
W
1.630
1.620
41.40
41.15
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (in millimeters) are given for general information only (1.00 inch = 25.4 mm).
3. Corners of case may be round or square.
4. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
FIGURE 5. PIN M3928/10-07 - Continued.
7
