MIL-DTL-3928/10F
Dimensions
Inches
Millimeters
Inches
Millimeters
Letter
Letter
Max
Min
Max
Min
Max
Min
Max
Min
A
.59
.53
15.0
13.5
M
2.72
2.66
69.1
67.6
B
3.47
3.41
88.1
86.6
N
1.545
1.535
39.2
39.0
C
2.945 2.935
74.80
74.55
P
.39
.33
9.9
8.4
D
2.53
2.47
64.3
62.7
Q
1.15
1.09
29.2
27.7
E
2.395 2.385
60.83
60.58
R
.59
.53
15.0
13.5
F
.18
.12
4.6
3.0
S
.50
.44
12.7
11.2
G
.30
.24
7.6
6.1
T
.873
.867
22.17
22.02
H
1.28
1.22
32.5
31.0
U
.873
.867
22.17
22.02
J
3.66
---
93.0
---
V
.10
.04
2.5
1.0
K
2.63
---
66.8
---
W
.185
.175
4.70
4.44
L
.69
.63
17.5
16.0
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (in millimeters) are given for general information only (1.00 inch = 25.4 mm).
3. Corners of case may be round or square.
4. Unless otherwise specified, tolerances are ± .010 (± 0.25 mm) for three place decimals and
± .03 (±0.8 mm) for two place decimals.
FIGURE 4. PIN M3928/10-06 - Continued.
5
