MIL-DTL-5815H
4.5.3 Failures. No failures are allowed.
4.6 Conformance inspection.
4.6.1 Inspection of product for delivery. Inspection of product for delivery shall consist of group A inspection.
4.6.1.1 Inspection lot. An inspection lot shall consist of all antennas of the same part number, produced under
essentially the same conditions, and offered for inspection at one time.
4.6.1.2 Group A inspection. Group A inspection shall consist of the examinations and tests specified in table III, in
the order shown. The inspections shall be performed on all antennas in each production lot.
TABLE III. Group A inspection.
Examination or test
Requirement paragraph
Method paragraph
Visual and mechanical examination
Marking
Workmanship
Impedance
Sampling probe impedance 1/
Sampling probe attenuation 1/
Seal
4.6.1.2.1 Sampling plan. Statistical sampling and inspection shall be in accordance with a random sample of
items selected in accordance with table IV. Acceptance shall be based upon a zero defective sampling plan. No
failures shall be permitted.
TABLE IV. Group A sampling plan.
Lot size
Sample size
1-13
100 percent
14-150
13
151-280
20
281-500
29
501-1200
34
1201-3200
42
3201-10,000
50
10,001-35,000
60
35,001-150,000
74
150,001-500,000
90
500,001 and over
102
4.6.1.2.2 Rejected lots. If an inspection lot is rejected, the supplier may rework it to correct the defects, or screen
out the defective units, and resubmit for reinspection. Such lots shall be separate from new lots, and shall be clearly
identified as reinspected lots.
4.6.2 Periodic inspection. Periodic inspection shall consist of group B. Except where the results of these
inspections show noncompliance with the applicable requirements (see 4.6.2.1.4), delivery of products which have
passed group A shall not be delayed pending the results of these periodic inspections.
4.6.2.1 Group B inspection. Group B inspection shall consist of the examinations and tests specified in table V, in
the order shown. Group B inspection shall be made on sample units selected from inspection lots that have passed
the group A inspection.
6
