MIL-DTL-24211C
TABLE III. Group A sampling plan.
Lot size
Sample size
1-13
100 percent
14-150
13
151-280
20
281-500
29
501-1200
34
1201-3200
42
3201-10,000
50
10,001-35,000
60
35,001-150,000
74
150,001-500,000
90
500,001 and over
102
4.5.1.3.2 Rejected lots. If an inspection lot is rejected, the contractor may rework it to correct the defects, or
screen out the defective units, and resubmit for re-inspection to the table III sampling plan. Such lots shall be
separate from new lots, and shall be clearly identified as re-inspected lots. If one or more defects are found in the
second sample, the lot is rejected and shall not be supplied to this specification. (NOTE: This corrective action
applies to the original defect found. If another defect type is found in the second sample, a re-screen for that defect
is also permitted.)
4.5.1.4 Group B inspection. Group B inspection shall consist of the tests specified in table IV.
TABLE IV. Group B inspection.
Test
Requirement paragraph
Method paragraph
Rubber adhesion
Salt atmosphere (corrosion)
4.6.3
Seal
RF leakage
4.5.1.4.1 Sampling plan. For the purpose of group B inspection, gaskets shall be in two size groups as listed in
table V. Group B inspection shall be performed on one sample per size group and inspection of one sample gasket
in a group shall fulfill the group B inspection requirements for the entire group. Inspection shall be performed on a
particular size group semi-annually if the manufacturer has been awarded a contract or order for a gasket in that
group.
Table V. Group B inspection size groups.
Group I - X-band and smaller
Group II - Larger than X-
band
M24211/1-001
M24211/2-001
M24211/1-002
M24211/2-002
M24211/1-003
M24211/2-003
M24211/1-004
M24211/2-004
M24211/1-005
M24211/2-005
M24211/1-006
M24211/2-006
M24211/2-009
M24211/2-007
M24211/2-010
M24211/2-008
M24211/2-011
5
